Description
- System of helical-bevel gearbox (HA/331, master) and bevel gearbox (E/285A, slave)
- HA/331 equipped with a reversing mechanism, designed for diesel-mechanically powered DMUs
- HA/331 and E/285A-gearboxes connected by a cardan shaft
Technical data
| Top speed (km/h) | 120 |
| Max. input torque (Nm) | 6,000 |
| Gear ratio | 3.31/2.865 |
| Max. input speed (rpm) | 2,965 |
| Shaft diameter (mm) | 180 (at bearing) |
| Reference | Stadler - RS1 Regioshuttle |
